PA 5241. 3-väg Kulventil Stål – PN16 – Fläns – L & T Port
APPLICATION
General use : Chemical industries, petrochemical industries, hydraulic installation, heating, water distribution, compressed air.
GENERAL CHARACTERISCS
From DN25 to DN150.
Full bore. Anti blow-out stem
PTFE seat filled with glass. Locking device
ISO 5211 mounting pad. Tightness on 3 ways L port.
Trunnion mounted ball valve from DN100 to DN150
Produktblad
Certifieringar
- ISO 5211
- ISO 9001
| Art.nr | Anslutning | Dim. | Material | Tryckklass | Bygglängd | Genomlopp | Offert |
|---|---|---|---|---|---|---|---|
| PA5241-25 | Fläns | 25 | PN16 | 185 | Fullt | ||
| PA5241-32 | Fläns | 32 | PN16 | 195 | Fullt | ||
| PA5241-40 | Fläns | 40 | PN16 | 232 | Fullt | ||
| PA5241-50 | Fläns | 50 | PN16 | 253 | Fullt | ||
| PA5241-65 | Fläns | 65 | PN16 | 278 | Fullt | ||
| PA5241-80 | Fläns | 80 | PN16 | 292,2 | Fullt | ||
| PA5241-100 | Fläns | 100 | PN16 | 360 | Fullt | ||
| PA5241-125 | Fläns | 125 | PN16 | 416 | Fullt | ||
| PA5241-150 | Fläns | 150 | PN16 | 473 | Fullt |
| Komponent | Material |
|---|---|
| Hus | ASTM A216 WCB |
| Kula | ASTM A351 CF8 |
| Säte | PTFE med 15% glasfiber |
| Ändstycke | ASTM A216 WCB |
| Spindel | Rostfritt stål 304 |
| Packbox | PTFE |
| Packboxpackning | PTFE med 25% grafit |
| Handtag | Rostfritt stål 304 (DN25-40), stål (DN50-150) |
