PA 4261. Klaffbackventil PN40 – Segjärn Fläns
General Characteristics
From DN 40 to 800,
Epoxy coated body and cover. Mounting in horizontal and vertical ascending position.
Simplicity in construction.Total lift swing at opening.
Reliable and efficient functionning. Strong contruction materials.
Noiseless construction.
Application
General use: clear and slightly charged water, pumping, piping, irrigation, sewage systems.
Produktblad
Certifieringar
- ISO 5208
- ISO 9001
| Art.nr | Anslutning | Dim. | Material | Tryckklass | Bygglängd | Genomlopp | Tillval | Offert |
|---|---|---|---|---|---|---|---|---|
| PA4261KB-40 | Fläns | 40 | Segjärn | PN40 | 180 | — | ||
| PA4261KB-50 | Fläns | 50 | Segjärn | PN40 | 200 | — | ||
| PA4261KB-65 | Fläns | 65 | Segjärn | PN40 | 240 | — | ||
| PA4261KB-80 | Fläns | 80 | Segjärn | PN40 | 260 | — | ||
| PA4261KB-100 | Fläns | 100 | Segjärn | PN40 | 300 | — | ||
| PA4261KB-125 | Fläns | 125 | Segjärn | PN40 | 350 | — | ||
| PA4261KB-150 | Fläns | 150 | Segjärn | PN40 | 400 | — | ||
| PA4261KB-200 | Fläns | 200 | Segjärn | PN40 | 500 | — | ||
| PA4261KB-250 | Fläns | 250 | Segjärn | PN40 | 600 | — | ||
| PA4261KB-300 | Fläns | 300 | Segjärn | PN40 | 700 | — | ||
| PA4261KB-350 | Fläns | 350 | Segjärn | PN40 | 800 | — | ||
| PA4261KB-400 | Fläns | 400 | Segjärn | PN40 | 900 | — | ||
| PA4261KB-450 | Fläns | 450 | Segjärn | PN40 | 1000 | — | ||
| PA4261KB-500 | Fläns | 500 | Segjärn | PN40 | 1100 | — | ||
| PA4261KB-600 | Fläns | 600 | Segjärn | PN40 | 1300 | — | ||
| PA4261KB-700 | Fläns | 700 | Segjärn | PN40 | 1500 | — | ||
| PA4261KB-800 | Fläns | 800 | Segjärn | PN40 | 1700 | — |
| Komponent | Material |
|---|---|
| Hus | Segjärn |
| Lock | Segjärn |
| Disk | Stål + EPDM (DN40–400), segjärn (DN450–800) |
| Spak | Segjärn |
| Axel | X20CR13 |
| Tätning | EPDM |
