PA6240. Kulbackventil – Syrafast stål – Fläns
General Characteristics
Design in accordance with standard NF EN 14341. Range : From DN50 to DN400.
Tight and working in horizontal or vertical position.
Low head loss. Full bore thanks to the moving of the ball.
Self-cleaning ball. Easy and quick disassembly cover.
Application
General uses : Waste water, stickly fluids, raising water (purification, water treatment, pumping).
Produktblad
Certifieringar
- ISO 5208
- ISO 9001
| Art.nr | Anslutning | Dim. | Material | Tryckklass | Bygglängd | Genomlopp | Tillval | Offert |
|---|---|---|---|---|---|---|---|---|
| PA6240-50 | Fläns | 50 | Syrafast stål | PN10/PN16 | 200 | — | ||
| PA6240-65 | Fläns | 65 | Syrafast stål | PN10/PN16 | 240 | — | ||
| PA6240-80 | Fläns | 80 | Syrafast stål | PN10/PN16 | 260 | — | ||
| PA6240-100 | Fläns | 100 | Syrafast stål | PN10/PN16 | 300 | — | ||
| PA6240-125 | Fläns | 125 | Syrafast stål | PN10/PN16 | 350 | — | ||
| PA6240-150 | Fläns | 150 | Syrafast stål | PN10/PN16 | 400 | — | ||
| PA6240-200 | Fläns | 200 | Syrafast stål | PN10 | 500 | — | ||
| PA6240-250 | Fläns | 250 | Rostfritt stål | PN10 | 600 | — | ||
| PA6240-300 | Fläns | 300 | Rostfritt stål | PN10 | 700 | — | ||
| PA6240-350 | Fläns | 350 | Rostfritt stål | PN10 | 800 | — | ||
| PA6240-400 | Fläns | 400 | Rostfritt stål | PN10 | 900 | — |
| Komponent | Material |
|---|---|
| Hus | DN50-200 rostfritt stål 316 (A351 CF8M), DN250-400 rostfritt stål |
| Lock | Rostfritt stål 316 (A351 CF8M) |
| Kula | DN50-200 aluminium + nitril, DN250-400 segjärn EN-GJS-400-15 + nitril |
| Packning | Nitril |
| Mutter | Rostfritt stål |
