PA6149 Kulbackventil – Syrafast stål – inv. gänga
General Characteristics
Ball type. Vertical position with ascendant fluid or horizontal position (respect the flow direction indicated by the arrow ).
Female / female threaded. Bolted bonnet for easy maintenance.
Stainless steel 316 body. FPM gasket.
Check valve tested individually at 3 bars of compressed air
Application
Usage general : waste water, viscous and dense fluids.
Produktblad
Certifieringar
- ISO 228-1
- ISO 9001
| Art.nr | Anslutning | Dim. | Material | Tryckklass | Bygglängd | Genomlopp | Tillval | Offert |
|---|---|---|---|---|---|---|---|---|
| PA6149-32 | Gänga | 32 | Syrafast stål | PN16 | 175 | — | ||
| PA6149-40 | Gänga | 40 | Syrafast stål | PN16 | 190 | — | ||
| PA6149-50 | Gänga | 50 | Syrafast stål | PN16 | 210 | — |
| Komponent | Material |
|---|---|
| Hus | Rostfritt stål ASTM A182 F316 |
| Lock | Rostfritt stål ASTM A182 F316 |
| Lockpackning | FPM |
| Kula | Aluminium FPM-belagd |
| Krage | Rostfritt stål ASTM A182 F316 |
| Nippel | Rostfritt stål ASTM A182 F316 |
| Förband | Rostfritt stål ASTM A182 F316 |
