PA 4241 CP. Klaffbackventil med hydraulisk motvikt PN16.
General Characteristics
Range : from DN 150 to DN 1000.
Low head losses. Maintenance free.
Complete sealing (double eccentric arrangement of disc). Mounting horizontally or vertically.
Bearings self lubrificated. With or without counterweight.
Application
General uses: drinkable water, dirty fluids, industry.
Produktblad
Certifieringar
- ISO 2531
- ISO 9001
| Art.nr | Anslutning | Dim. | Material | Tryckklass | Bygglängd | Genomlopp | Tillval | Offert |
|---|---|---|---|---|---|---|---|---|
| PA4241CP-150 | Fläns | 150 | Segjärn | PN16 | 210 | — | ||
| PA4241CP-200 | Fläns | 200 | Segjärn | PN16 | 230 | — | ||
| PA4241CP-250 | Fläns | 250 | Segjärn | PN16 | 250 | — | ||
| PA4241CP-300 | Fläns | 300 | Segjärn | PN16 | 270 | — | ||
| PA4241CP-350 | Fläns | 350 | Segjärn | PN16 | 290 | — | ||
| PA4241CP-400 | Fläns | 400 | Segjärn | PN16 | 310 | — | ||
| PA4241CP-450 | Fläns | 450 | Segjärn | PN16 | 330 | — | ||
| PA4241CP-500 | Fläns | 500 | Segjärn | PN16 | 350 | — | ||
| PA4241CP-600 | Fläns | 600 | Segjärn | PN16 | 390 | — | ||
| PA4241CP-700 | Fläns | 700 | Segjärn | PN16 | 430 | — | ||
| PA4241CP-800 | Fläns | 800 | Segjärn | PN16 | 470 | — | ||
| PA4241CP-900 | Fläns | 900 | Segjärn | PN16 | 510 | — | ||
| PA4241CP-1000 | Fläns | 1000 | Segjärn | PN16 | 550 | — |
| Komponent | Material |
|---|---|
| Hus | Segjärn GGG50 |
| Disk | Segjärn GGG50 |
| Axel | Rostfritt stål X20 Cr13 |
| Bussning | Brons |
| Packning | EPDM |
| Spak | S235JR |
