PA546-2 Kilslidsventil Broby byggmått – Syrafast stål – PN16
Gate valve in cast steel DN 50 – 350 PN 16
| Designation | Material |
|---|---|
| Body | Cast Steel GS-C25 |
| Bonnet | Cast Steel GS-C25 |
| Seat | Graphite |
| Disc | Cast steel |
| Disc holder <DN125 Disc holder <DN150 |
Nodular cast iron Cast steel GS-C25 |
| Stem | Stainless steel |
| Disc nut | Steel |
| Body/nut | Steel zincplated |
| Gland packing | Graphite |
| Bolt | Steel zincplated |
| Gland | Nodular cast iron |
| Bushing | Gunmetal LG2 |
| Washer | Gunmetal LG2 |
| Handwheel | Cast iron epoxy painted |
